The DC Dental X-Ray Machine is an advanced imaging system designed to deliver high-quality, stable, and precise dental radiographs. Unlike conventional AC machines, DC technology provides a constant X-ray output, resulting in sharper images and reduced radiation exposure.
This makes it an ideal choice for modern dental clinics that require accuracy, efficiency, and patient safety.
🔹 Key Features
✅ Portable & Lightweight Design (Less than 2.5 kg)
✅ Rechargeable Li-ion Battery for cordless operation
✅ High Output Performance (70kV DC) for clear imaging
✅ Long Battery Backup – More than 500 exposures per charge
✅ Low Radiation & Safe Operation
✅ Precise Focal Spot (0.4 mm) for sharp image quality
✅ Quick Exposure Time (0.05s – 1.0s)
✅ User-Friendly & Easy to Handle
✅ Ideal for Dental Clinics & Mobile Use
🔹 Technical Specifications
| Parameter | Specification |
|---|---|
| Power Input | 21.6 V |
| Battery Type | Li-ion, Replaceable |
| Battery Capacity | 2600 mAh |
| Input Voltage | 100–265 V AC / 50 Hz |
| Maximum Duty Cycle | 1:60 |
| Focal Spot | 0.4 mm |
| Tube Current | 2.3 mA |
| Output Voltage | 70 kV DC |
| Exposure Time | 0.05 sec – 1.0 sec |
| X-rays per Charge | > 500 exposures |
| Source to Skin Distance | 20 cm (Fixed) |
| Irradiated Field | 60 mm Round |
| Weight | < 2.5 kg |
